Galvanized Double Layer Grain Chain Conveyor

Basic Information
Place of Origin: JIANGSU CHINA
Brand Name: GAMMA
Certification: ISO 9001
Model Number: TGSU
Minimum Order Quantity: 1 pcs
Packaging Details: Steel Frame
Delivery Time: 40-60days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 100 pcs per Month
Detail Information
Thickness Of Cover Sheet: 2mm Thickness Of Bottom Plate: 5-6mm
Thickness Of Side Wall: 4mm Power: 2.2kw-10kw
Accessories: Speed Sensor Function: Blockages Proof
Capacity: Large Type: Single Layer & Double Layer
High Light:

Galvanized Grain Chain Conveyor


Double Layer Grain Chain Conveyor


Single Layer scraper chain conveyor

Product Description

Galvanized Raw Material Conveying Scraper Grain Chain Conveyor




1. U-type buried scraper can feed multiple and more points out of material.

2. With heavy boot device and automatic alarm system.

3. The guide rail is made of special material.

4. The scraper blade is made of polyurethane material, easy to operate and extend its working life.

5. Chain for high strength high wearing resistance, long conveying distance.

6. The engine tail has advanced design, easy operate, it can extend its working life.

     It is widely used for port and pier, oil, chemical, grain, flour, malt, alcohol, semi-finished products feed and other materials.



Models Information :


Model Max Power (KW) Capacity (T/H) Scraper chain linear velocity (M/S)
TGSUl6 ≤7.5 10-20 0.35-0.5
TGSU20 ≤11 20-25 0.35-0.5
TGSU25 ≤15 25-40 0.35-0.5
TGSU32 ≤22 40-65 0.35-0.5
TGSU40 ≤30 65-100 0.35-0.5






 Galvanized Double Layer Grain Chain Conveyor 0


 Galvanized Double Layer Grain Chain Conveyor 1





Q: Who Are We?

A: We are Wuxi Gamma Agriculture Technology Co.,Ltd a professional and reliable company mainly engaged in feed equipment.


Q: What Srevice Can We Provide?

A: We have feed production line, single machine and device parts for you.


Q: When will our problems be solved?

A: At the moment you tell us, we have contacted our professional technicians, you don't have to worry.


Q: how can we guarantee quality?
A: We have relative certificates, and our machine have one year warranty
if you have need, final Inspection before shipment.


Q: How to safe the goods for you?

A: we also can sign insurance in the contract to help you insure.
